Chapter 3
PCI Express Configuration
Main Advanced Chipset M.I.B III Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Configure PCI Express 16X
speed B0: D1:F0 Gen 1- Gen
3
NB PCI Express Configuration
PCI Express 16X
PCI Express 16X Speed Auto
PCI Express Configuration
PCI E 1
PCIe Speed Auto
The item in the menu shows the information of PCI Express Configuration.
This item allows user to configure the PCI Express 16X/ PCIE1/ PCIE2 speed.
PCI Express 16X/ PCIE1/ PCIE2 Speed (Auto)
PCI E 2
PCIe Speed Auto
To Next Page
