ECS LIVA Z

LIVA Z MINI PC USER MANUAL
3
Chapter 1
• 3 x Type-A USB 3.0 ports and 1 x Type-C USB
3.0 port
• 1 x Power button
• 1 x Audio combo jack
• 1 x Front USB 2.0 header
• 1 x 2-pin Front LED header
• 1 x 2-pin battery connector
• 1 x 3-pin System Cooling Fan connector
• 1 x 4-pin Digital Microphone connector
• 2 x M.2 slots
• 1 x Mini PLUS connector (LPC_CONN)
• 1 x HDD connector (SATA_CONN)
Internal I/O
Connectors &
Headers
Power Supply
• Adapter 19V, 40W/65W
Dimension
• 117mm x 128mm x 32mm
VESA
• 100mm x 100mm
