ECS LIVA Z User Manual

8
LIVA Z MINI PC USER MANUAL
Chapter 1
Table of Motherboard Components
LABEL COMPONENTS
1. SoC
Intel
®
Apollo lake SoC
2. AUDIO_JACK Audio jack
3. USB3F4 Front USB 3.0 port (Type-C)
4. F_USB Front USB 2.0 header
5. USB3F1~3 Front USB 3.0 ports (Type-A)
6. F_LED Front LED header
7. PWR_BTN Power On/Off button
8. DIMM1~2 Single channel DDR3L SDRAM SO-DIMM
9. BT1 Battery connector
10. SYS_FAN 3-pin System cooling fan connector
11. NGFF1~2 M.2 support wireless card and SSD card
12. DMIC1 4-pin Digital microphone connector
13. LPC_CONN Mini PLUS connector
14. SATA_CONN HDD connector

ECS LIVA Z Specifications

General

Memory slots	2x SO-DIMM
Internal memory	4 GB
Internal memory type	DDR3L-SDRAM
Maximum internal memory	8 GB
Storage media	eMMC
Optical drive type	No
Total storage capacity	64 GB
Ethernet LAN	Yes
Bluetooth version	4.0
Cabling technology	10/100/1000Base-T(X)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 500
HDMI version	1.4
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Chassis type	-
Product color	Black
Placement supported	Horizontal
Operating system architecture	64-bit
Product type	Mini PC
Processor cache	2 MB
Processor model	N3350
Processor family	Intel® Celeron® N
Processor frequency	1.1 GHz
Power supply input voltage	100 - 240 V
Intel Identity Protection Technology version	1.00
Intel Small Business Advantage (SBA) version	0.00

Weight and Dimensions

Depth	128 mm
Width	117 mm
Height	33 mm
Weight	- g
