ECS LIVA Z User Manual

22
LIVA Z MINI PC USER MANUAL
Chapter 2
:Select Screen
F1:General Help
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
+/- : Change Opt.
Enter : Select


:Select Item
Version 2.18.1263. Copyright (C) 2016 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2016 American Megatrends, Inc.
eMMC Configuration
eMMC Support [Enabled]
eMMC Information
SanDisk DF4032 BD218B32 (31.2 GB)
Enable/Disable
Embedded Multi
Media Card Support
eMMC Support (Enabled)
Use this item to enable or disable Embedded Multi Media Card
support.
eMMC Information (SanDisk DF4032 BD218B32 (31.2 GB))
This item shows the information of eMMC storage.

eMMC Configuration
This page provides the information and configuration for
Embedded Multimedia Card.
Advanced
Press <Esc> to return to the Advanced Menu page.

ECS LIVA Z Specifications

General

Memory slots	2x SO-DIMM
Internal memory	4 GB
Internal memory type	DDR3L-SDRAM
Maximum internal memory	8 GB
Storage media	eMMC
Optical drive type	No
Total storage capacity	64 GB
Ethernet LAN	Yes
Bluetooth version	4.0
Cabling technology	10/100/1000Base-T(X)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 500
HDMI version	1.4
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Chassis type	-
Product color	Black
Placement supported	Horizontal
Operating system architecture	64-bit
Product type	Mini PC
Processor cache	2 MB
Processor model	N3350
Processor family	Intel® Celeron® N
Processor frequency	1.1 GHz
Power supply input voltage	100 - 240 V
Intel Identity Protection Technology version	1.00
Intel Small Business Advantage (SBA) version	0.00

Weight and Dimensions

Depth	128 mm
Width	117 mm
Height	33 mm
Weight	- g
