LIVA Z MINI PC USER MANUAL
Chapter 2
Seiral Port 4 Configuration
Scroll to this item and press <Enter> to view the following screen:

:Select Screen
F1:General Help
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
+/- : Change Opt.
Enter : Select


:Select Item
Version 2.18.1263. Copyright (C) 2016 American Megatrends, Inc.
Serial Port 4 Configuration
Serial Port [Enabled]
Device Settings IO=2E8h; IRQ=3
Change Settings [Auto]
Enable/Disable Serial
Port (COM)
Serial Port (Enabled)
This item allows you to enable or disable the serial port.
Device Settings (IO=2E8h; IRQ=3)
This item shows the resource consumed by the serial port.
Change Settings* (Auto)
Use this item to change device settings.
Aptio Setup Utility - Copyright (C) 2016 American Megatrends, Inc.
Advanced
Press <Esc> to return to the Advanced Menu page.
Press <Esc> to return to the Super IO Configuration page.
*The setting of this item will be nonadjustable.
