Installation
2
Installation
The Card reader is fairly easy to install and operate.
It is a Plug and Play installation. To avoid complications during
the installation process, please follow the easy steps provided in
this chapter.
Hardware Installation
1
Install the IC card drive into an available drive bay.
2
Connect the USB cable to the USB header located on your mainboard.
Refer to the pin definition table (next page) for correct orientation.
