EDAC 222-02 - Specifications

EDAC 222-02 AUTO ALARM DIALLER - 3 -
SPECIFICATIONS
Connections
1.5 mm screw terminals are provided for all electrical connections to the EDAC 222-02.
 Power
Voltage 12-15V DC
Current 40mA idle
80-100mA active
NOTE: Power supply must comply with Telecom PTC101 requirements.
 Inputs Two, clean-contact, voltage-free trigger Inputs such as relay
contacts, a float switch or a microswitch are required.
WARNING: Applying voltage to the Inputs of the auto-dialler may damage the EDAC
222-02 and will void the product warranty.
 Outputs Two Outputs are available. Open collector type. Max current
120mA.
 Telecom Line Two RJ11 sockets. A suitable cord can be provided
compatible with the wall socket in your country. The inner
two pins of the RJ11 socket are used for TIP + RING.
Mechanical
 Dimensions 192mm length x 110mm width x 35mm height.
 Weight 250gm
 Cabinet Aluminium base with screw on (M4 pozi-drive) aluminium lid.
 Finish White epoxy powder coat.
 Mounting 4 x 4mm mounting holes in the base of the cabinet.
 Line in/Line out RJ11 Modem standard (only the 2 inner pins are used as Tip
+ Ring).
Messages
 Site Message Four seconds of high-quality, user-recordable speech. The
site message should clearly identify the site where the EDAC
222-02 is located.
 Input Messages Eight seconds of high-quality, user-recordable speech per
Input. The Input messages should clearly identify the event
and what action needs to be taken.
 Acknowledged Four seconds of high-quality, user-recordable speech to
identify when message Inputs have been acknowledged.
 Idle Message Four seconds of high-quality, user-recordable speech to
identify when the EDAC 222-02 Inputs are in an idle state.
