MT-206/MT-207 Trolley Installation Guide
- 4 -
Accessories:
Item Description Qty. (pcs) Spares (pcs)
A Ф12 Normal type spring washer 5 1
B Ф12 Normal type plain washer 5 1
C 3-inch Medical caster 5 /
D M10×50 bolt 1 /
E Ф10 Normal type spring washer 1 1
F Ф10 Normal type plain washer 1 1
G M6×25 spacing bolt
1 1
H Cross recessed pan head screw M5×14
4 2
I
M4×25 Cross recessed countersunk head
screw (only applicable to iM9 series, iM8
series, iM80 patient monitor)
4 2
M4×20 Cross recessed countersunk head
screw (only applicable to iM60, iM70
patient monitor)
4 2
M3×12 Cross recessed pan head screw
(only applicable to M3 series, iM50
monitor)
3 2
J 17# normal open spanner 1 /
NOTE：
1 Choose the appropriate I screws for different monitors.
2 The lower basket and flange should be used at the same time.
3 More screws are provided for standby in the package. Refer to the above
table for the actual numbers of screws required in installation.
