Eddystone S79005 - Page 27

Print Date 08/04/14 Page 27 of 34 S79005-00MA-05
Reverted System Data Block
(15 extra bytes reverted in response to # ? Y sequence)
Title Status Possible Values
(ASCII)
Tx_Data1 Tx data status request byte third byte echo
fixed at Y
Tx_Data2 Tx system normal status N O
Tx_Data3 Tx forward power status N L F X
Tx_Data4 Tx reverse power status N H X
Tx_Data5 Tx combiner temp status N H X
Tx_Data6 Tx fans/cooling status N F X
Tx_Data7 Psu2 48-52V line status N E F
Tx_Data8 Psu1 48-52V line status N E F
Tx_Data9 Psu4 48-52V line status N F
Tx_Data10 Psu3 48-52V line status N F
Tx_Data11 Tx power auto/man status T Y
Tx_Data12 Tx power (man) start/mute status M S Z
Tx_Data13 Tx power (true) high/lo setting status H L X
Tx_Data14 Tx power (auto) start/mute status M S
Tx_Data15 Tx power (auto) high/lo setting status H L
Tx_Data16 Tx status 8 bit EOR checksum (of 2-
15 inc. only
Reverted Drive Data Block
(15 extra bytes reverted in response to # ? Z sequence)
Title Status Possible Values
(ASCII)
Dri_Data1 Drive data status request byte third byte echo
fixed at Z
Dri_Data2 Drive C/O auto/man status T Y
Dri_Data3 Drive on A/B status A B
Dri_Data4 Drive preferred A/B status A B
Dri_Data5 Drive active/passive status P U
Dri_Data6 Drive A slow status N F
Dri_Data7 Drive A fast status N F
Dri_Data8 Drive B slow status N F
Dri_Data9 Drive B fast status N F
Dri_Data10 Drive A pass/fail N F
Dri_Data11 Drive B pass/fail N F
Dri_Data12 Drive C/O count 0 1 2 3 4
Dri_Data13 Tx external mute status M S
Dri_Data14 Tx external high/low status H L
Dri_Data15 Tx external interlock status M S
Dri_Data16 Drive status 8 bit EOR checksum (of
2-15 inc. only
