Reverted Output Data Block
(15 extra bytes reverted in response to # ? 0 sequence)
Title Status Possible Values
(ASCII)
Op_Data1 Output data status request byte third byte echo
fixed at ASCII 0
Op_Data2
Output Forward Power Level MSB (kW)
Op_Data3 Output Forward Power Level MSB-1 (kW)
Op_Data4 Output Forward Power Level LSB+1 (kW)
Op_Data5 Output Forward Power Level LSB (kW)
Op_Data6 Output Reverse Power Level MSB (W)
Op_Data7 Output Reverse Power Level MSB-1 (W)
Op_Data8 Output Reverse Power Level LSB (W)
Op_Data9 Output Temperature Level MSB (deg.C)
Op_Data10 Output Temperature Level MSB-1 (deg.C)
Op_Data11 Output Temperature Level LSB (deg.C)
Op_Data12 Output OS number MSB
Op_Data13 Output OS number MSB-1
Op_Data14 Output OS number LSB
X or
+ (plus)
- (minus)
. (decimal point)
Null (blank)
0 to 9 (inc)
Op_Data15 Output Tx Type A (500W, 1 Psu)
B (500W, 2 Psu)
C (1kW)
D (2kW)
E (3kW)
F (4kW)
G (5kW Comp.)
H (5kW)
I (8kW)
J (10kW)
Op_Data16 Output data 8 bit EOR checksum (of 2-15
inc. only)
Reverted Amplifier Data Block
(15 extra bytes reverted in response to # ? 1 to # ? X sequences)
Title Function Possible Values
(ASCII)
Amp_Data1 Amp number 1-40 third byte echo
of ASCII 1-9 : ; <
= >? @ A-X
Amp_Data2 Amp Forward Power Level MSB (W)
Amp_Data3 Amp Forward Power Level MSB-1 (W)
Amp_Data4 Amp Forward Power Level LSB (W)
Amp_Data5 Amp Current Level MSB (Amps)
Amp_Data6 Amp Current Level MSB-1 (Amps)
Amp_Data7 Amp Current Level LSB+1 (Amps)
Amp_Data8 Amp Current Level LSB (Amps)
Amp_Data9 Amp Temperature Level MSB (deg.C)
Amp_Data10 Amp Temperature Level MSB-1 (deg.C)
Amp_Data11 Amp Temperature Level LSB (deg.C)
X or
< (less than)
+ (plus)
- (minus)
. (decimal point)
Null (blank),
0 t0 9 (inc.)
Amp_Data12 Amp Forward Power status N F X
Amp_Data13 Amp Current status N H X
Amp_Data14 Amp Temperature status N H X
Amp_Data15 Amp Reverse Power status N H X
Amp_Data16 Amp data 8 bit EOR checksum (of 2-15
inc. only)
