Technical manual SOLO/SOLO3000 – V1.5 p.8/12
3) Connecting reader on GENIUS control unit
(?) Data sheet:
Be sure to use the same pair for A and B
Be sure to separate the supply from the bus RS485
Characteristic: Sensitive connection
Screen: Mandatory
To achieve 1200m (2730 ft), you need to install a 120 resistor at each end of the network
between points A and B (see above).
Note: The total length must not exceed the recommended distance.
