Edesa L511 - Cleaning the Accessible Filter

Clean the accessible fil-
ter whenever the draina-
ge pump is blocked by
foreign bodies.
a Loosen the base by
gently pulling on the
sides and turning
downwards. Then
undo the fasteners.
If there is no side
access, introduce a
small screwdriver in
the three slots on
the upper part of the
base, in order to
lever it and loosen
the hooks.
b Use a plate or other
container under the
filter to collect the
water that will be
released when it is
loosened.
c Turn the filter a
quarter- or halfway
sideways towards
the left. Water will
start to come out.
d When you are finis-
hed taking the water
out of the washing
machine, turn the fil-
ter around several
times until you can
take it out fully.
e Remove any objects
or fluff that may be in
the filter.
f Replace the filter
and the base in their
places.
In order to avoid burns,
this operation should
not be carried out when
the wash water tempe-
rature is over 30ºC.
IMPORTANT
2
CLEANING THE ACCESSIBLE FILTER
