7
1.29 Do not dispose your water heater in the garbage, but hand it
be recycled.
2. INSTALLATION
- Refer to the corresponding diagrams p.1 & 2 (see
- Make sure to keep free space of 300 mm below
pipes for the exchange of the heating element.
3. HYDRAULIC CONNECTION
- It is necessary to clean the supply piping prior to the hydraulic connection. The connection to the
hot water outlet is to be carried out with a cast iron or steel sleeve or a dielectric connector, to
- INSTALLATION PRESSURISED: See fig. ❺ & ❻, p.2. Always install a new safety device on
- During heating up, water dripping may occur at the valve, do not obstruct the dripping.
The safety device if supplied does not meet the criteria for installation on French territory (Mainland
4. ELECTRICAL CONNECTION
- Refer to the corresponding diagrams p. 3 (See fig. ❼, ❽, ❾, ❿, ⓫
- The water heater can be connected and operated only on AC 230V or on AC 220-240V in
accordance with the rating plate of the appliance. Connect the heater with a rigid cable with
conductors 2,5 mm
2
housing cover.
- Directly connect devices with a cable or plug. In France, a product with plug is strictly prohibited
and cannot be sold and installed.
- Always connect the earth conductor of the cable to the earth ground wire or connect the earth
conductor to the appropriate terminal identified by the symbol
. This connection is compulsory
for safety reasons. The earth wire green - yellow must be longer than those of phases. The
installation must be equipped, upstream of the appliance, with a bipolar cut-out device (minimum
in insulated material, electrical circuits shall be protected by a differential circuit breaker 30 mA
adapted to local standards.
- Thermal cut-off: All products are equipped with a thermostat including a thermal circuit breaker
with manual reset, which cuts the power in case of overheating. In case the security trips A: Cut
the power before any operation. B: remove the plastic cover. C: Check the electrical connection.
D: Reset security. In case of repetitive tripping, replace the thermostat. Never bypass safety or
regulation thermostat. Connect the power only on the sockets or thermostat input.
Diameter Vertical installation
ØD380
ØD433
See g.❶B & ❷B & ❸
ØD445 See g.❶A & ❷A
