Located on the top, center of the face plate.
On: Unit is on when display / logo is lit up in red.
Off: Unit is off if the display is dark.
Logo / Power Display
Located on the lower right of the rear panel in the
power entry module.
On: When right side of rocker (with - ) is down
Off: When left side of rocker (with 0 ) is down
On / Off Switch
Located on the rear panel of the amplifier.
Speaker fuses: Located above each set of speaker
terminal.
8 amp fast blow 5 x 20 mm fuse in each
(For:USA and Overseas units)
AC Power fuses: Located in the power entry module.
10 amp slow blow 5 x20mm (USA units)
5 amp slow blow 5 x20 mm (Overseas)
Never replace fuses with a type or value different than
those specified
Fuse Holders
Amplifier Placement
Choose a place that will support the weight of
your amplifier and allow you access to the
back for cable connections. Your amplifier dissipates heat
through air circulation and must be kept free of any obstruc-
tion that would reduce air flow. Always place your amplifier
on a hard surface and allow at least 2 inches of free space
above for ventilation. Also allow adequate clearance for the
AC cord and signal cables to bend behind your amplifier,
we recommend leaving at least 6 inches for clearance.
NL10 with
option
clear top.
NL12
page 3 page 4
