CONNECTIONS
GROUND CABLE
REMOTE TURN ON CABLE
RCA CABLES
AUTO TURN ON (HIGH LEVEL INPUT ONLY)
• At least 10 gauge cable should be used for the ground connection to the amplier.
• The amplier ground should be connected directly to the chassis of the vehicle, to bare metal.
• The cable length should be kept to an absolute minimum.
• It is not recommended that you connect the ground cable to the vehicles seatbelts anchor point.
• A minimum of 18 gauge cable should be used for this connection.
• The cable should be run with exactly the same care and attention as the power cable and taken
back to the source (headunit) and joined to the remote cable provided.
• If the source (headunit) does not have a remote turn on cable then a 12v supply should be used.
This will require a switch to be tted inline to enable the amplier to be turned on and off.
Remember that if this switch is left on you will atten the car battery.
• Please take extra care when running these cables from the source to the amplier. Ensure that
they are placed away from all items that can generate any interference, wiring harnesses etc.
• It is recommended that the RCA cables should be run on opposite sides of the car to the
previously installed power cables if possible, to avoid the cable picking up interference.
• The EDGE Active enclosures feature an auto turn on circuit called Autosense.
• This circuit allows the amplier to switch on and off without a remote turn on wire when
using high level input, for low level input (RCA) it will still be necessary to connect the
remote turn on wire from the headunit.
• When the connected source (headunit) is turned on the amplier will turn on
automatically, after the connected source (headunit) is turned off the amplier will
shut down.
