EdgeStar AP14009COM-1 Service Manual

6
NO.
PART NAME
NO.
PART NAME
1
BASE PLATE
36
INDOOR TEMPERATURE SENSOR
2
CASTOR
37
BRACKET
3
DRAIN PLUG
38
POWER SUPPLY CORD
4
DRAIN BUCKET COVER-B
39
BAR
5
DRAIN BUCKET COVER-A
40
AIR DEFLECTOR
6
FLOAT BRACKET
41
DISCHARGE GRILLE
7
FLOAT
42
TOP COVER PLATE
8
FLOAT SWITCH
43
BRACKET
9
WATER FLINGER MOTOR
44
PUSH BUTTONS
10
COMPRESSOR
45
LIGHT BOARD
11
RUBBER FOOT
46
CONTROL PCB
12
DISCHARGE PIPE
47
FRONT PANEL
13
SUCTION PIPE
48
REAR PANEL
14
CONDENSER
49
AIR FILTER
15
CAPILLARY TUBE
50
TOP COVER PLATE
16
FAN HOUSING
51
REMOTE CONTROL
17
BLOWER WHEEL
52
Y TUBE
18
FAN MOTOR
53
SENSOR FOR REMOTE CONTROL
19
FAN HOUSING
54
BRACKET
20
CAPACITOR FOR FAN MOTOR
55
EXHAUST HOSE
21
CAPACITOR FOR COMPRESSOR
56
EXHAUST HOSE CONNECTOR
22
CAPACITOR COVER
57
GRATED CONNECTOR
23
MIDDLE PLATE
58
EXHAUST CAP
24
EVAPORATOR
59
WINDOW PLATE WITH HOLES
25
FAN HOUSING
60
WINDOW PLATE
26
BLOWER WHEEL
61
DRAIN PIPE CONNECTOR
27
FAN MOTOR
62
DRAINAGE PIPE
28
FAN HOUSING
63
REMOTE CONTROL BATTERY
29
SCREEN
64
QUICK CONNECTOR
30
CAPACITOR FOR FAN MOTOR
65
BRACKET
31
BRACKET
66
PUSH BUTTON SWITCH
32
CAPACITOR COVER
67
RUBBER
33
MAIN PCB COVER
68
METAL BRACKET
34
MAIN PCB
69
FIX CLIP
35
PCB BRACKET
70
EVAPORATOR SENSOR
