EdgeStar CWR360FD - Parts Identification; Front View

EdgeStar Wine Refrigerator 2
Parts Identification
Front View
TIP:
Gather the model and serial
number from the product label
on the back of unit and write
them down before installing
the wine refrigerator.
Control Panel
Handles
Stainless Steel Door
*Full Wood Shelves (10)
Front Vent
**Half Wood Shelves (2)
NOTE:
*The top five shelves on
each side are full size
shelves.
**The bottom shelf on each
side is only a half size shelf
due to placement of
compressor.
NOTE:
Bottle Placement:
To obtain maximum
capacity stagger three
bottles per shelf as
shown in picture.
