Edgetec TRIFLO - Diagram 3 Air Tube Connections; Activating Air Bleed

EDGETEC SYSTEMS PTY LTD Part # 9-2100 MAY 2012
4
Diagram 3 Air Tube Connections
Diagram 4 Activating Air Bleed
*Important - Only Activate Air Bleed if pump does not
prime (refer page 10)
Prior to August 2012
After August 2012
Twist Cap Air Bleed - Rotate
Fully Anticlockwise to Open
Attach 10 mm
Flexible drain tube
(Not Supplied)
