Edgetech 701 DIGITAL LINK User Manual

3-4
=
FRONT PANEL
Data Connector
RJ-45 Standard Ethernet connection for connecting to the external topside
processor.
Sync Connector
It provides an input connection for a TTL external trigger that is sent to the
towfish.
Sea Cable Connector
SubConn MCBH4F female connector to sea cable going out to tow vehicle.
Table 3-1: 701-DL Controls, Indicators, and Connections

Edgetech 701 DIGITAL LINK Specifications

General

Brand	Edgetech
Model	701 DIGITAL LINK
Category	Marine Equipment
Language	English
