Installing the EdgeMarc on a Desktop, Shelf, or Tray
1. Remove the EdgeMarc device and accessories from the shipping container
2. Place the device on a flat, dry surface such as a desktop, shelf, or tray
Installing the EdgeMarc in a Rack
Install the EdgeMarc in a 19” rack using the rack mount kit supplied with the device. Before installing the
EdgeMarc in a rack, take note of the following conditions:
Elevated Operating Ambient: if installed in a closed or multi-unit rack assembly, the operating
ambient temperature of the rack environment may be greater than room ambient. Therefore,
consideration should be given to installing the equipment in an environment compatible with the
maximum ambient temperature specified by the manufacturer.
Reduced Air Flow: installation of the equipment in a rack should be such that the amount of
airflow required for safe operation of the equipment is not compromised. Mechanical Loading—
Mounting of the equipment in the rack should be such that a hazardous condition is not achieved
due to uneven mechanical loading.
Circuit Overloading: consideration should be given to the connection of the equipment to the
supply circuit and the effect that overloading of the circuits might have on overcurrent protection
and supply wiring. Appropriate consideration of equipment nameplate ratings should be used
when addressing this concern.
Reliable Earthing: reliable earthing of rack-mounted equipment should be maintained. Particular
attention should be given to supply connections other than direct connections to the branch circuit
(for example, use of power strips).
The EdgeMarc 2900e feature two sets of three mounting holes on each side so the device can be
reversibly mounted with the back facing out.
1. Remove the EdgeMarc device and accessories from the shipping container
2. Attach the rack mount ears to both sides of the EdgeMarc chassis with the supplied screws
3. Install the chassis in the rack with rack mount screws
