Diagram and Function Description
: PLAY
: MUTE
LED ON : PLAY
LED OFF : MUTE
POWER OFF
POWER ON
Òô Á¿Òô Á¿Òô Á¿Òô Á¿
AUXAUX
VOLUMEVOLUME
MUTEMUTE
THE AUDIO ARTISTTHE AUDIO ARTIST
++
--
connects to AC electrical outlet
1. POWER (Power On/Off)
2. BASS (Bass Volume Control Knob)
3. Line In (Audio Signal Input Port)
4. Speaker Output (Audio Signal Output Socket)
11. AUX ( Connect to DVD Player,
Radio, etc.)
5. Power line
6. Wired Remote Control connecting socket
7. Headphone Socket
8. LED Indicator Light
9 VOLUME (Main Volume Control Knob)
10. MUTE (Mute button)
Subwoofer face panel
Subwoofer rear panel
Wired remote
control under view
Wired remote
control side view
Wired remote
control front view
