71
日本語
各部の名称と主な機能
6.電源ケーブル
7.電源スイッチ
8.AUX入力
9.ライン入力
10.光入力
11.同軸入力
12.状態インジケーター
13.ペアリングボタン
(サブウーファーをアクティブスピーカーと
ペアリング)
14.パッシブスピーカーに接続
15.ボリュームダウンボタン
押す:ボリュームダウン
Bluetoothを切断するには、約3秒押し下げ
たままにします(Bluetoothモード)
16.電源オン/オフ/モードスイッチ/モードイ
ンジケーター
押す:モードスイッチ
Bluetooth:青色の光が点滅します
AUX:緑色の光が1回点滅します
ライン:緑色の光が2回点滅します
光:赤色の光が1回点滅します
同軸:赤色の光が2回点滅します
長押し:電源オン/オフ
17.ボリュームアップボタン
押す:ボリュームアップ
15 16 17
7
8
6
9
10
11
12
13
14

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the EDIFIER M601DB and is the answer not in the manual?

EDIFIER M601DB Specifications

General IconGeneral
Wi-Fi-
Bluetooth version5.1
Audio amplifierYes
Product colorBlack
RMS rated power- W
Recommended usageUniversal
Remote control typeIR
Audio output channels- channels
Card reader integratedNo
Connectivity technologyWired & Wireless
Digital audio optical in1
Subwoofer frequency range50 - 170 Hz
Subwoofer dimensions (WxDxH)276.86 x 300 x 335 mm
Amplifier classD
Amplification device form factorBuilt-in
Number of satellite speakers2
Satellite speakers RMS power40 W
Satellite speaker frequency range140 - 20000 Hz
Satellite speaker dimensions (WxDxH)127 x 226 x 152 mm
Power sourceAC
