EDIFIER M601DB User Manual

8
English
Audio inputs
or
1. AUX/Line In mode
• Press the " " button on the active speaker, or press the " " or " " button on the remote control to switch to AUX
or Line In mode (the green indicator will flash and then will be steady lit);
• Connect audio source (mobile phone, tablet, etc.) to the "AUX" or "Line In" input port (note color matching) on the rear panel
of the active speaker using audio cable;
• Play music on the connected device and adjust the settings to a desired level.
2. Optical mode
• Press the " " button on the active speaker, or press the " " button on the remote control to switch to optical mode (the
red indicator will flash once and then will be steady lit);
• Connect audio source (DVD, Set Top Box, etc.) to the "OPT" input port on the rear panel of the active speaker using fiber optic
audio cable;
• Play music on the connected device and adjust the settings to a desired level.
3. Coaxial mode
• Press the " " button on the active speaker, or press the " " button on the remote control to switch to coaxial mode
(the red indicator will flash twice and then will be steady lit);
• Connect audio source to the "COAX" input port on the rear panel of the active speaker using coaxial cable (coaxial cable not
included);
• Play music on the connected device and adjust the settings to a desired level.

EDIFIER M601DB Specifications

General

Wi-Fi	-
Bluetooth version	5.1
Audio amplifier	Yes
Product color	Black
RMS rated power	- W
Recommended usage	Universal
Remote control type	IR
Audio output channels	- channels
Card reader integrated	No
Connectivity technology	Wired & Wireless
Digital audio optical in	1
Subwoofer frequency range	50 - 170 Hz
Subwoofer dimensions (WxDxH)	276.86 x 300 x 335 mm
Amplifier class	D
Amplification device form factor	Built-in
Number of satellite speakers	2
Satellite speakers RMS power	40 W
Satellite speaker frequency range	140 - 20000 Hz
Satellite speaker dimensions (WxDxH)	127 x 226 x 152 mm
Power source	AC
