4
English
Illustrations
1. Connect to passive speaker
2. Audio input connector
3. Connect to external subwoofer
4. Power cable
5. Power switch
6. Connect to active speaker
7. Treble dial
8. Bass dial
9. Master volume control dial
Press: input mode switch
Press and hold: power on/off
Press and hold: disconnect Bluetooth
in Bluetooth mode
10. Power indicator
11. Infrared receiver/input indicator
Green: Line in 1/Line in 2 mode
Blue: Bluetooth mode
⑦
⑧
⑩
⑨
⑥
③
②
①
④
⑤
