EDIFIER R1855DB

4
English
Illustration
1. Treble dial
2. Bass dial
3. Master volume dial
Press to switch audio source: Line In 1→Line In 2→
Optical→Coaxial→Bluetooth
Press and hold: Disconnect Bluetooth connection
4. Line In input
5. Optical input
6. Coaxial input
7. Bass output
8. Connect to passive speaker port
9. Power switch
10. Power cord
11. Connect to active speaker port
12. LED indicator:
Blue: Bluetooth mode
Green: Line In 1 mode (The light will flash once)
Line In 2 mode (The light will flash twice)
Red: Optical mode (The light will flash once)
Coaxial mode (The light will flash twice)
12
1
4
5
2
3
9
10
6
7
8
11
