EDIFIER S1000W

LINE 1 LINE 2
OPT COAX
Audio Inputs
or
1. Line In 1/Line In 2 mode
• Press the "Volume/Input" button on the active speaker, or press the "LINE 1" or "LINE 2" button on the remote control to
switch to Line In 1/Line In 2 mode (the green indicator will blink and then will be steady lit);
• Connect audio source (mobile phone, tablet, etc.) to the "Line In 1" or "Line In 2" input port (note color matching) on the
rear panel of the active speaker using audio cable;
• Play music on the connected device and adjust the settings to a desired level.
2. Optical mode
• Press the "Volume/Input" button on the active speaker, or press the "OPT" button on the remote control to switch to optical
mode (the red indicator will blink once and then will be steady lit);
• Connect audio source (DVD, Set Top Box, etc.) to the "OPT" input port on the rear panel of the active speaker using fiber
optic audio cable;
• Play music on the connected device and adjust the settings to a desired level.
LINE 1 LINE 2
OPT COAX
