or
Press the “INPUT” button on wired controller or “5.1CH” key on remote control until the LCD displays “5.1CH”.
Connect the “5.1CH” connector ports to your device with the 6P-6P connecting cable.
Play the music on the connected device and adjust the settings to a desired level.
Dual RCA-Dual RCA audio cables are needed if you want to play music through certain devices (not included in the
box).
Page 8 Specifications:
Power output: L/R/C/SL/SR: RMS 60W × 5 (DRC ON)
SW: RMS 120W × 2 (DRC ON)
Signal to noise ratio: ≥85dBA
Input type: 5.1/CD/AUX
Input sensitivity: 900mV±50mV
Frequency response: Satellite: 130Hz~20KHz (±5dB)
Subwoofer: 42Hz~140Hz (±5dB)
Adjustment: Wired controller, remote control
Bass unit: 10 inch (260mm), 8ohm
Mid-range unit: 3½ inch (92mm), 4ohm
Treble unit: Φ25mm silk dome, 6ohm
Dimension: FR/FL/SR/SL: 116(W) × 203(H) ×160(D) mm
C: 316(W) × 117 (H) ×157 (D) mm
Subwoofer: 367(W) × 397(H) × 489(D) mm
Net weight: Satellite/Subwoofer: Approx. 13kg/21.3kg
Gross weight: Satellite/Subwoofer: Approx. 14.5kg/21.4kg
Page 9 Troubleshooting
● Switch the EDIFIER S550 encore off then on and reconnect to the audio source.
● Ensure the devices are workable and connected correctly.
