EDIFIER X600 User Manual

Operating
1
2
3 Playing the audio device
CONNECTING
Connect the satellite speakers to the output RCA on the
back panel of the Sub-woofer. Please note to match the color,
red to red and white to white.
Connect the subwoofer to the Audio device.
Using Audio connecting cord , connect the Line-input port
of the subwoofer to Line-out of the Audio Device (Such as the
computer, Discman, etc).
Plug the AC power plug into the wall outlet and turn on the
power switch, Now your speaker system is ready for Use.
Adjusting the volume control and Bass control , then you can
enjoy the music.
SPECIFICATIONS
Notice
Edifier assumes no responsibility for any errors that may appear
in this manual. Information contained herein is subject to change
without notice.
Operating
2
Total Power Output : RMS 8W x 2 + 14W(THD=10%)
Input Impedance: 10K Ohm
Input Sensitive: 450 mV
Bass Unit: 7" Aluminum coil, 4 Ohm
M 3" Paper coil, 4 Ohm
Tweeter Unit: 1"
Dimension(Subwoofer): 241(W) x 229(H) x 279(D)mm
Dimension(Satellite): 91(W) x 202(H) x141(D)mm
Gross Weight: About 7.3 Kg
id-range Unit:
PV membrane dome

EDIFIER X600 Specifications

General

Product color	Black
Volume control	Rotary
RMS rated power	30 W
Housing material	MDF
Recommended usage	PC
Remotely operated	No
Audio output channels	2.1 channels
Magnetically shielded	Yes
Signal-to-Noise Ratio (SNR)	85 dB
Total Harmonic Distortion (THD)	10 %
Amplification device form factor	Built-in
Amplifier/receiver input interface type	3.5 mm jack
Satellite speaker type	2-way
Number of satellite speakers	2
Satellite speakers RMS power	8 W
Satellite speaker frequency range	190 - 20000 Hz
Satellite speaker tweeter diameter	0.75 \
Satellite speaker tweeters quantity	1
Satellite speaker dimensions (WxDxH)	91 x 141 x 202 mm
Satellite speaker mid-range driver diameter	3 \
Subwoofer type	Active subwoofer
Subwoofer frequency range	20 - 170 Hz
Subwoofer dimensions (WxDxH)	241 x 279 x 229 mm
Subwoofer driver diameter (imperial)	7 \
Power source	AC
Cables included	AUX
