20
ROUTINE PRINTER CLEANING
Follow the procedure below for routine cleaning:
Repeatedly running the "T" shaped card through the printer cleans the cleaning roller in order to maintain print quality and extend the service life of
the print head.
1 Open the printer cover.
2 Remove the ribbon as shown on the diagram.
3 Close the cover and make sure it has clicked shut.
4 Open the card feeder.
5 Using the gauge, adjust the card thickness to the MAX position.
1 2
3
4 5
To Next Page
