DIMENSIONS AND POSITIONS OF INLETS AND OUTLETS
24
ENGLISH
Taken serial
Rs232
boiler drain
cock
Ø 40 air
Ø 80 smoke
safety valve ½"
inlet ¾"
top-up ½"
outlet ¾"
sk ecoidro_multilingue_vers F 28 04 2011.qxp 29/04/2011 15.26 Pagina 25
