EdilKamin Extra Series User Manual

ENGLISH
41
MOUNTING THE COVERING
QUEBEC / DETROIT
TORONTO / BOSTON
n° cod.
1
Red lower front panel 1 642050
1
Off-white lower front panel 1 642040
2
Red upper front panel 1 642070
2
Off-white lower front panel 1 642060
3
Red large side panel 2 642090
3
Off-white large side panel 2 642080
4
Red small side panel 6 46160
4
Off-white small side panel 6 645750
5
Red top 1 642130
5
Off-white top 1 642120
6
Screw T.B. 6x12 12 284380
7
Piastrine ceramiche 10 647670
8
Screw 4,8x10 16 266940
9
Door ceramic blocking plate 2 387530
10
Front ceramic blocking plate 2 388890
11
Screw T.E. 6x16 2 18650
12
Screw 4,2x6,5 2 235990
13
Spacer 6 266670
pz
cod.
1
Red lower front panel 1 642050
1
Off-white lower front panel 1 642040
2
Red upper front panel 1 642070
2
Off-white lower front panel 1 642060
5
Red top 1 642130
5
Off-white top 1 642120
6
Screw T.B. 6x12 2 284380
9
Door ceramic blocking plate 2 387530
10
Front ceramic blocking plate 2 388890
11
Screw T.E. 6x16 2 18650
12
Screw 4,2x6,5 2 235990
MONTREAL / MIAMI
4
4
4
4
4
4
13
10
12
10
11
2
3
3
1
5
6
9
9
6
7
8
12
10
11
2
1
5
6
9
10
9
pz
cod.
1
Right side 3 655220
2
Top 1 655210
3
Left side 3 657430
2
1
3
3
3
1
1

EdilKamin Extra Series Specifications

General

Brand	EdilKamin
Model	Extra Series
Category	Stove
Language	English
