- 19 -
ENGLISH
FUSE
* two fuses are inserted
on the socket behind
the stove, fi tted with a
switch one is functional
and the other is spare.
*
*
FEATURES
THERMOTECHNICAL CHARACTERISTICS
Nominal power 8,0 kW
Effi ciency nominal power 89,2 %
Emissions CO (13% O2) nominal power 0,07 %
Smoke mass nominal power 5,5 g/s
Reduced power 3,4 kW
Effi ciency reduced power 92,6 %
Emissions CO (13% O2) reduced power 0,028 %
Smoke mass reduced power 2,9 g/s
Maximum overheated smoke 175 °C
Minimum draught 12 / 5 Pa
Autonomy (min/max) 6 / 15 hours
Fuel consumption (min/max) 0,8 / 1,9 kg/h
Hopper capacity 15 kg
Heatable volume * 210 m³
Weight including packaging (steel/ceramic) 169/187 kg
Smoke outlet pipe diameter (male) 80 mm
Air intake pipe diameter (male) 40 mm
* The heatable room dimensions are calculated on the basis of
pellets with an lhv of at least 4300 kcal/kg and home insulation
in compliance with Italian law 10/91, and subsequent changes
together with an expected heat output of 33 Kcal/m³ per hour.
* It is also important to consider the position of the stove in the
room to be heated.
ELECTRICAL CHARACTERISTICS
Power supply 230Vac +/- 10% 50 Hz
On/off switch Yes
Average power consumption 150 W
Power consumption during ignition 400 W
Remote control frequency Infrared
Protection on mains power supply** F4 AL, 250 Fuse
Protection on electronic circuit board F4 AL, 250 Fuse
The data shown above is purely indicative.
EDILKAMIN s.p.a. reserves the right to make changes to
these products to improve their performance with no prior
warning.
992
546
552
74,9106,6
546
315,2
368
181,5
99
55
55
18
10,5
7,5
55
31,5
37
