- 25 -
ENGLISH
TECHNICALAND HEATING SPECIFICATIONS
N.B.: DATA PROJECT (Refer to standard EN 13229)
* The heatable room dimensions are calculated on the basis home insulation in compliance with Italian law 10/91, and subsequent
changes together with an expected heat output of 33 Kcal/m³ per hour.
* It is also important to consider the position of the boiler-Ŏ replace in the room to be heated.
* * boiler temperature is 70° - (ðT=25K)
The data shown above is purely indicative.
EDILKAMIN s.p.a. reserves the right to change the products at its discretion without notice.
THE INLET AND OUTLET PIPES MUST BE CROSSED FOR THIS TO FUNCTION PROPERLY
THE DIAMETER OF THE CHIMNEY FLUE TO BE USED MUST BE ASSESSED BY THE INSTALLER ACCOR-
DING TO THE HEIGHT OF THE CHIMNEY FLUE ITSELF.
15-15/CS 23-23/CS 28-28/CS
Thermal output (burnt) 18,5 27,8 34,8 kW
Rated power 14,8 22,2 27,8 kW
Water heating power 12,1 18,2 22,8 kW
Approx. overall efŎ ciency 80 80 80 %
Approx. water efŎ ciency 82 82 82 %
Class efŎ ciency (EN 303-5) > 3 > 3 > 3 -
ø female smoke outlet 18 22 25 cm
Maximum operating pressure 1,5 1,5 1,5 bar
Fuel consumption 4,5 7 8,5 kg/h
Water capacity 50 100 130 litres
Heating capacity * 355 535 670 m³
Weight including packing 240 285 325 kg
Hot sanitary water production (kit 1- 3 - N3 - N3bis)** 13-14 13-14 13-14 litres/min
ø external air inlet 12,5 12,5 12,5 cm
System return (male) 1” 1” 1” inches
System ŏ ow (male) 1” 1” 1” inches
