Edimax BR-6428nS V3 User Manual

7
The device’s five available modes are outlined below:
Wi-Fi Router Mode
The device connects to your modem and provides
2.4GHz Internet (wireless and Ethernet) access
for your network devices.
Access Point Mode
The device connects to an existing router via
Ethernet cable and provides 2.4GHz Internet
(wireless and Ethernet) access for your network
devices.
Range Extender
Mode
The device connects wirelessly to your existing
2.4GHz network and repeats the wireless
signal(s).
Wireless Bridge Mode
The device connects to a network device for
example: TV, gaming console, or media player via
Ethernet cable and acts as a wireless receiver,
allowing the network device to join your Wi-Fi
network.
WISP Mode
The device connects wirelessly to your Wireless
Internet Service Provider and provides 2.4GHz
Internet (wireless and Ethernet) access for your
network devices.

Edimax BR-6428nS V3 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Input current	1 A
Rack mounting	-
Supported protocols	PPPoE, static IP, dynamic IP, PPTP & L2TP
WLAN data transfer rates supported	11, 54, 300 Mbit/s
Ethernet LAN (RJ-45) ports	4
Security algorithms	128-bit WEP, 64-bit WEP, WPA-PSK, WPA2-PSK
Antennas quantity	2
Antenna gain level (max)	5 dBi
Product color	White
LED indicators	Activity, LAN, Link, Power, WAN
Flash memory	4 MB
Certification	CE, FCC, NCC, BSMI
Internal memory	32 MB
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)
Output voltage	5 V

Weight and Dimensions

Depth	162 mm
Width	190 mm
Height	42 mm
Weight	245 g
