Edimax EW-7206APg Specifications

Wireless LAN Access Point
Wireless LAN Access Point
Features
• Complies with the IEEE 802.11b (DSSS) 2.4GHz specification
• Supports 2.400~2.4835 GHz frequency band, 1~14 channels
• High data rate up to 54Mbps network speed
• Auto rate fallback in case of obstacles or interferences
• Supports WPA / WPA2 security enhanced function
• Supports WDS(Wireless Distributed System) bridge mode
• Provides station mode to act as a wireless LAN client station
• Supports roaming link integrity
• Supports authentication for wireless connectivity based on ESSID
• Provides 64/128 bit key length WEP data encryption
• Provides MAC access control
• Provides DHCP server
• Supports Web-based configuration
• Firmware upgradeable via Web
• Compact-size design
Specification
18 dBmTransmit Power
2 MB NOR FlashFlash
8MB SDRAMRAM
FCC, CECertification
10~90% (Non-Condensing)Humidity
10~40
Oc
Temperature
30(H)*127(W)*96(D) mm Dimension
12V DC, 0.4A Switch Power Adaptor Power
RP-SMA Detachable Antenna x 1Antenna
10/100M UTP Port x 1LAN Port
Realtek RTL8225RF
Realtek RTL8186CPU
EW-7206APgProduct
Edimax Worldwide

Edimax EW-7206APg Specifications

General

2.4 GHz	Yes
Frequency band	2.4 - 2.4835 GHz
Maximum data transfer rate	100 Mbit/s
Ethernet LAN (RJ-45) ports	1
Security algorithms	EAP-MD5, SSID, WPA, WPA2
Compliance industry standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.3, IEEE 802.3u
Flash memory	2 MB
Internal memory	8 MB
Processor model	Realtek RTL8186
Antenna connector type	RP-SMA
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC Class B, CE Mark
Power requirements	12V DC, 0.4A

Weight and Dimensions

Dimensions (WxDxH)	127 x 96 x 30 mm
