NETWORK SETUP DIAGRAM AND RELATED PRODUCTS
* Maximum performance may vary depending on network conditions and environmental factors.
An example of how the EW-7316ug can be setup:
• Connect the EW-7316Ug wireless adapter to your computer.
• Connect to wireless 802.11b/g access point or broadband router.
FEATURES AND TECHNICAL SPECIFICATIONS
• Works with both IEEE 802.11b and IEEE 802.11g products.
• High-speed data transfer rate - up to 54Mbps.
• High throughput supports multi-media data bandwidth requirement.
• Supports 64/128-bit WEP , WPA/WPA2 (TKIP with IEEE 802.1x) and AES data encryption
• Automatic fallback increases data security and reliability.
HARDWARE INTERFACE STANDARD FREQUENCY BAND
USB2.0 Interface
Internal Printing Antenna
IEEE802.11b, IEEE802.11g 2.4000~2.4835GHz (Industrial
Scientific Medical Band)
DATA RATE MODULATION LED
11b: 1/2/5.5/11Mbps
11g: 6/9/12/24/36/48/54Mbps
auto fallback
11g : OFDM with BPSK, QPSK, 16QAM, 64QAM
11b : BPSK, QPSK, CCK
Link / Active
TX / RX
SECURITY DIMENSION HUMIDITY & TEMPERATURE
WEP 64/128, WPA, WPA2, AES 9(H) x 27(W) x 87(D) mm Max. 95% (Non Condensing)
32~131°F (0 ~55°C)
SYSTEM REQUIREMENTS OUTPUT POWER CERTIFICATIONS
Windows 98/ME/2000/XP/2003/Vista
Mac 10.3.x / 10.4.x
Linux Kernel 2.4 / 2.6
11g: 15±1dBm
• 11b: 17±1dBm
CE, FCC
