*Driver for Windows 98SE/Me/2000/XP:
I. Install the Hardware
Note. This step is for EW-7628Ig PCI card only, if you are going
to setting EW-7608Pg Cardbus, please jump to chapter II.
directly and do not install the adaptor into your computer
before installing the software program from the CD.
Installation Procedure
1. Turn off your computer and remove its cover.
2. Insert the PCI card to an available PCI slot firmly.
3. Secure this card to the rear of the computer chassis and put
back the cover.
4. Secure the antenna to the antenna connector of the card.
5. Turn on the computer.
Guidelines for the Hardware Installation
Please observe the following guidelines when you are installing
the PCI card to the Desktop PC:
Avoid placing the PC close to obstacles
Obstructions such as concrete walls and thick metals limit radio
signal penetration and reduce the throughput and the coverage
range of the PCI card and Place the PC as high as possible
The higher the PC is placed, the better the performance.
Adjust the antenna position
The card has two antennas for signal reception and one antenna
for high power signal transmission. The antennas on the right
and left side are for signal reception and should be set
perpendicular (90 degrees) to each other. The central one is for
signal transmission and should be pulled up about 45 degree.
Please refer to the illustration below:
To Next Page
