edishine HCFM02A - Page 6

05
70%
70%
100%
100%
100%(completely) remove 2 screws from the moun�ng plate for later use.
remove 2 screws from the moun�ng plate.
REMOVE SCREWS FROM MOUNTING BRACKET
Outlet box
Moun�ng Plate Screws
Moun�ng Plate
Flat Washers
Spring Washers
MOUNTING PLATE ASSEMBLING
70%
