EDLUND 625M - EDLUND CROWN PUNCH CAN OPENER Controls and Features

CALL TOLL FREE 1-800-772-2126 7
EDLUND CROWN PUNCH CAN OPENER Controls and Features
NOTE: The model shown in Figure 2 may look slightly different from your machine.
Figure 2
"T" Bolts
Base
Right Actuator Button
Left Actuator Button
(not shown)
Guard Ring
Crown Punch
Retainer Clip
Adjustment Handle
Magnet (if applicable)
(shown on left but right
side is most common)
Splash Guard
Air In
Quick disconnect
(not shown)
Knockout Pins
(not shown)
