GENERAL
Input Voltage AC
100-120Vac/200-240V ± 10% auto range, 50/60Hz ± 5%, max. current 6.3A for SE 7430, SE 7440 & SE 7441
100-120Vac/200-240V ± 10% auto range, 50/60Hz ± 5%, max. current 15A for SE 7451 & SE 7452
PLC Remote Control
Input：Test, ReSet, Interlock, Recall File 1 through 15
Output：Pass, Fail, Test-in-Process
Memory
2000 steps, allow the User create different memories and steps. But each memory limit max. 200 steps and
results
Display
4.3＂Color Display(Touch Panel)
Calibration
Build-in software and external calibrated meters
Alarm Volume Setting
Range：0-9; 0 = OFF, 1 is softest volume, 9 is loudest volume
Built-in Scanner
Module
OPTION
-
YES
-
-
External Scanner Port
YES
YES
YES
YES
YES
USB & RS232
Interface
YES
YES
YES
YES
YES
GPIB Interface
OPTION
OPTION
OPTION
OPTION
OPTION
Multinational
Language
The operating screen can Select different language including English/Traditional Chinese/Simplified
Chinese/Japanese
CE Compliance
YES
Environment
0-40ºC, 20-80%RH
Dimension(W × H ×
D), mm
430 × 88.1 × 400
430 × 88.1 × 400
430 × 133 × 400
430 × 88.1 × 400
430 × 88.1 × 400
Weight
17.6Kg
18.6Kg
20Kg
21Kg
23.4Kg
*product specifications are subject to change without notice.
*1. SE 7451 and SE 7452 short circuit current > 200mA
*2. Environment requirement：humidity < 60%RH(no condensation, no scanner), When I < 150nA.
*3. Only one interface can be selected among RS232 & USB interface card or GPIB & Ethernet interface card.
【Ordering Information】
OPT.798 True Negative Voltage for DCW and IR
OPT.799 GB Output 40A for SE 7440, SE 7441, SE 7452
OPT.7002 DC Continuity Test Function for SE 7430, SE 7451
OPT.7004 Built-in Scanner 8W for SE 7430
OPT.7006 Built-in Scanner 8W + 8 Cont. for SE 7430
OPT.7009 JigA/JigB
OPT.7015 6KVAC/7.5KVDC Output
