EEC SE 7452 - Programming and Operating the SE Series

20
Measurement
Range
Resolution
Accuracy
Voltage, KV(AC/DC)
0.00-7.50
0.01
±(1% of reading + 0.5% of Range)
Voltage, Vdc
(IR only)
0-1000
1
±(1% of reading + 0.5% of Range)
1001-6000
1
±(1% of reading + 0.5% of Range)
AC Total Current, mA
(Auto range)
0.000-3.500
0.001
±(2% of reading + 3 counts)
3.00-40.00
(SE 7430 , SE 7440 , SE 7441)
0.01
3.00-99.99
(SE 7451 , SE 7452)
0.01
±(2% of reading + 6 counts)
100.0
(SE 7451 , SE 7452)
0.1
AC Total Current, mA
(Fixed range)
0.000-3.500
0.001
±(2% of reading + 2 counts)
0.00-40.00
(SE 7430 , SE 7440 , SE 7441)
0.01
±(2% of reading + 2 counts)
Additional error when reading < 6%
of range for ±(0.1% of range)
0.00-99.99
(SE 7451 , SE 7452)
0.01
±(2% of reading + 2 counts)
Additional error when reading < 3%
of range for ±(0.1% of range)
AC Real Current , mA
0.000-9.999
0.001
±(3% of reading + 50µA)
All Ranges PF > 0.1 , V > 250VAC
10.00-99.99
0.01
DC Current, nA
(Auto/Fixed Range)
0.0-350.0
0.1
±(2% of reading + 10 counts)
Low Range is ON.
DC Current, µA
(Auto Range)
0.300-3.500
0.001
3.00-35.00
0.01
30.0-350.0
0.1
±(2% of reading + 2 counts)
DC Current, µA
(Fixed Range)
0.000-3.500
0.001
±(2% of reading + 10 counts)
Low Range is ON.
Additional error when reading < 6%
of range for ±(0.1% of range)
0.00-35.00
0.01
00.0-350.0
0.1
±(2% of reading + 2 counts)
DC Current, mA
(Auto Range)
0.300-3.500
0.001
3.00-10.00
0.01
DC Current, mA
(Fixed Range)
0.000-3.500
0.001
±(2% of reading + 2 counts)
Additional error when reading < 6%
of range for ±(0.1% of range)
0.00-10.00
0.01
±(2% of reading + 2 counts)
Additional error when reading < 6%
of range for ±(0.2% of range)
AC Current, A (GB)
0.00-40.00
0.01
±(2% of reading + 0.5% of Range)
Resistance, mΩ (GB)
0-600
1
3.00-32.00 A,
±(2 % of reading + 2 counts)
Resistance, Ω
(Continuity)
0.000-1.000
0.001
±(1% of reading + 3 counts)
1.01-10.00
0.01
10.1-100.0
0.1
101-1000
1
1001-10000
1
±(1% of reading + 10 counts)
