ALWAYS SHUT DOWN THE POWER TO YOUR ELECTRICAL PANEL FIRST AND PROCEED WITH CAUTION!
For example, if you have a single tariff meter you should find four cables exiting the meter (see Diagram
A). The feed cable is the live cable exiting from the meter to the fuse box or main switch. Clip the
Sensor to Cable 4.
Diagram A Diagram B
Diagram C Diagram D
