The photovoltaic solar inverter is constructed for vertical assembly.
Never assemble the photovoltaic solar inverter in a horizontal
position and make sure it does not tilt forward if assembled outdoors.
Fig. 4-2 - 2 Ambient conditions for assembly (positioning)
When selecting the assembly location for the photovoltaic solar
inverter, you must ensure that there is sufficient heat dissipation.
The following minimum amounts of free space around the
photovoltaic solar inverter must be maintained:
1 Spacing of at least 20 cm
2 Spacing of at least 5 cm
Fig. 4-2 - 3 Ambient conditions for assembly (spacings)
