Photovoltaic Solar Inverter Series ES
Technical Data
ES series
73
ES2200
ES3300
ES4200
ES5000
Control
Panel
LCD display
Input DC voltage / input direct current / input DC power /
output AC voltage / output alternating current / output
frequency / output AC power /
Energy output / internal temperature / cooling element
temperature / status message / error message
LED display
Red:
Grounding fault or
DC input isolation fault
Yellow:
Supply conditions do not
correspond to the
input standard of the
photovoltaic solar inverter
Green:
Performance of solar cells
is above or below 5 % of
the nominal performance
of the
photovoltaic solar inverter
Operating keys
Navigation keys / function key / enter key
Safety
Mains
Over-/ under-voltage, over-/ under-frequency,
grounding fault, DC isolation error, no isolated
operation
Short circuit
DC input:
Reverse pole protection / electronic switching
AC output:
Output relay / electronic switching
EPO
(emergency
power off)
The photovoltaic solar inverter switches off immediately
Over-
temperature
≤ 50 °C (122 °F) at full capacity
≥ 50 °C(122 °F) at reduced capacity
Certification
Safety
Europe VDE0126-1-1, EN50178, IEC62103
EMI/EMC
EN 61000-6-1, EN 61000-6-2,
EN 61000-6-3, EN 61000-6-4
** The nominal range should be between 150 VDC and 500 VDC to achieve nominal power.
