6
B
Separate the Crossbar ⑦ and you will find the Crossbar Rail inside.
Crossbar End
Crossbar Rail
Crossbar End
Insert one of the Crossbar Ends into the one of the Lifting Columns ③ and secure with screws.
Attach the Side Bracket ⑥ to one of the Lifting Columns.
12
Allen Key
4mm
Repeat the same step for the other Lifting Column.
STEP 1
Repeat the same step for the other Lifting Column.
STEP 2
STEP 3
Allen Key
4mm
Step 2 Assembly
Side Bracket
A
12
Allen Key
4mm
