4
When prompted to place the EFI ES-2000 in the calibration cradle, make sure that the
white tile cover on the cradle is open (the slider is drawn back) and that the
EFI ES-2000 aperture is in full contact with the white tile. If you do not place the
EFI ES-2000 correctly in the calibration cradle, it does not return accurate
measurements. For best results, keep the white tile properly cleaned, as described in
“Maintenance and cleaning” on page6.
Note: You must use the calibration cradle that was packaged with your EFI ES-2000.
The calibration cradle has the same serial number as your EFI ES-2000.
EFI ES-2000 instrument settings in Color Profiler Suite
When you use the EFI ES-2000 with Color Profiler Suite, you can set the instrument
settings:
• Measurement mode: When you measure a strip, select the type of measurement
(described in Strip measurement).
• Use ruler: If this option is selected, the positioning sensor on the underside of the
EFI ES-2000 reads the stripes on the ruler to determine the position of the
EFI ES-2000 when you measure a strip. The use of the ruler is required for strip
measurement in two passes (described in Strip measurement).
• Large patch size: If this option is selected, larger patches are printed to allow for
better measurements with a low-resolution printer. The measurement method is
the same for regular and for large patches.
Single-patch measurement
Use the patch guide to measure a single patch.
To measure a single patch
1 Attach the EFI ES-2000 to the patch guide by inserting the connector on the patch guide
into the rear slot of the EFI ES-2000.
The EFI ES-2000 aperture fits in the round hole of the patch guide.
2 Position the aperture of the EFI ES-2000 in the middle of the patch that you want to
measure.
3 Press and release the button on the side of the EFI ES-2000.
The status lights on the EFI ES-2000 are off when the measurement has been recorded.
