3
Setup
The EFI ES-2000 setup is performed by connecting the EFI ES-2000 to a computer.
To set up the EFI ES-2000
1 Connect the EFI ES-2000 to the computer.
Connect the USB cable of the EFI ES-2000 to a free USB port on your computer, or to a
USB hub that features a separate power supply.
Note: Because of its power requirements, the EFI ES-2000 will not work if it is plugged
into the USB port on your keyboard.
2 Start the application that uses the EFI ES-2000.
For more information, see the documentation that accompanies the application.
Status indicator lights
The EFI ES-2000 is equipped with lights that indicate device status. When the
instrument is used with Fiery software, the lights have the following behavior.
Note: If the EFI ES-2000 is used in EFI ES-1000 compatibility mode (as a replacement
for the EFI ES-1000), the lights may not operate.
Measuring color samples
You can measure color samples using two different methods: single-patch
measurement and strip measurement.
EFI ES-2000 calibration
Before starting to measure color samples, you are prompted to place the EFI ES-2000
on the calibration cradle. White point calibration is used to calibrate the
spectrophotometer and ensure consistent measurements.
Lights Status
Off The EFI ES-2000 is not connected to your computer or the
software is not running.
Solid white The EFI ES-2000 is connected but needs an initial calibration
or the instrument calibration failed.
Blinking blue The EFI ES-2000 is ready to take measurements.
Blinks green twice The measurement was successful.
Blinks red twice A calibration error or measurement error occurred.
