Control bar
1 Manual hand brake lever 2* Brake lock (Parking lock)
3 Brake adjuster 4** Speed / Reverse switch
5 Twist throttle 6*** Battery voltage display
7 Hazard light switch 8 Turning indicator
Model: Explorer (MK1.5) Control bar
Caution:
* Pull brake lever fully before engaging, do NOT fold scooter with brake lock on.
** Speed Switch:
I - Pavement mode (4mph) 0 - Reverse II - Road mode (8mph).
*** Battery voltage display:
29 = Full 24 and below = charging required (Number will uctuate depending
on terrain).
Rev. A, English 8
