Components
1 Backrest frame 2 Backrest pad
3 Accelerator/gradual brake lever 4 Handle bar
5 Steering column 6 Steering stem folding lock
7 Steering stem/frame latch 8 Front motor
9 Front brake lock lever * 10 Stainless steel hinges
11 Footrest and battery compartment 12 Controller compartment
13 Hinge to fold footrest 14 2 inch suitcase wheels
15 10 inch Rear wheels 16 Main frame
17 Main seat pad 18 Rear seat pad
*The brake is on the other side of wheel, the above image is for illustra-
tion purpose only.
