EGG QUAIL - Detaching and Attaching Seat Unit; Using the 5-Point Safety Harness; Adjusting Shoulder Strap Height

11
10. Using the 5-point safety harness.
Fit together the two connectors on the harness
straps and push firmly into the buckle housing
until they click together. To open the harness press
in the grey button on the buckle housing and the
two connectors will release from the main buckle.
IMPORTANT: Ensure the buckle and connectors
are fully engaged before use.
10a. As your child grows, the height of the
shoulder straps can be adjusted. Remove the
magnetic panel on the back of the seat by pulling
it out from the bottom.
10
9b. Push both levers with your thumbs and lift the
seat up and off the chassis to detach it.
9c. To fit the seat unit to the chassis, position the
folded seat unit above the unfolded chassis, align
the central hubs on the seat unit with the central
hubs on the chassis and lower the seat unit until it
clicks and locks into position. Unfold the seat base
to engage the seat locks and then fold the back of
the seat away from the seat base to the recline
position of your choice.
WARNING: Ensure the seat unit is locked in place
on the chassis before use.
NB: The seat unit can be fitted facing in either
direction.
9b
9c
10
10a
PUSH
DOWN
P
U
S
H
D
O
W
N
ALIGN
ALIGN
P
USH
PULL
